AutoMemoryTools

A persistent, file-based long-term memory toolkit for AI agents. Complements the built-in session/conversation history by giving agents a durable store that survives across conversations — user preferences, project context, behavioral feedback, and external references — organized in a dedicated memories directory.

Long-term memory vs. conversation history

	Conversation history	AutoMemoryTools (long-term memory)
Scope	Current session only	Persists across sessions
Storage	In-process (RAM / ChatMemory)	Files on disk
Content	Full message exchange — every turn	Curated facts worth keeping forever
Size	Bounded by context window	Grows over time; agent loads selectively
Managed by	Spring AI ChatMemory / advisors	Agent via tool calls

Use conversation history for the short-term working context of the current task. Use AutoMemoryTools for facts that should still be available in the next conversation, next week, or next month — things the agent would otherwise have to re-learn from scratch every time.

Features: - Six targeted tools covering the full memory lifecycle (view, create, edit, insert, delete, rename) - All operations scoped to a sandboxed memories root — path traversal and absolute path injection blocked - Automatic creation of the memories directory and parent subdirectories - YAML frontmatter conventions for typed memories (user, feedback, project, reference) - MEMORY.md index pattern — a single always-loaded file pointing to all memory entries - UTF-8 throughout; trailing-newline preservation on insert - Companion system prompt included as a classpath resource

Quick Start

AutoMemoryTools memoryTools = AutoMemoryTools.builder()
    .memoriesDir("/path/to/memory")
    .build();

ChatClient chatClient = chatClientBuilder
    .defaultSystem(systemPrompt)            // include AUTO_MEMORY_TOOLS_SYSTEM_PROMPT.md
    .defaultTools(memoryTools)
    .defaultAdvisors(ToolCallAdvisor.builder().build())
    .build();

Load the companion system prompt from the classpath (available inside the spring-ai-agent-utils jar):

@Value("classpath:/prompt/AUTO_MEMORY_TOOLS_SYSTEM_PROMPT.md")
Resource memorySystemPrompt;

// Inject the memories root path into the prompt template
chatClientBuilder.defaultSystem(p -> p
    .text(toString(memorySystemPrompt))
    .param("MEMORIES_ROOT_DIERCTORY", memoryDir));

Memory File Convention

Each memory is a Markdown file with a YAML frontmatter header:

---
name: short name
description: one-line description — used to judge relevance in future conversations
type: user | feedback | project | reference
---

Memory content here.

**Why:** reason this was recorded
**How to apply:** when this guidance kicks in

Memory Types

Type	Purpose	When to save
user	User's role, goals, expertise, preferences	When you learn details about the user's background
feedback	How to approach work — corrections AND validated approaches	When the user corrects you or confirms a non-obvious choice
project	Ongoing work, decisions, deadlines not in code/git	When you learn who is doing what, why, or by when
reference	Pointers to external systems (Linear, dashboards, Slack)	When you learn about external resources and their purpose

MEMORY.md Index

MEMORY.md is the always-loaded index. Every memory file must have a corresponding one-line entry:

- [Title](filename.md) — one-line hook describing what's stored (≤150 chars)

The agent reads MEMORY.md at the start of a session to decide which memory files to load. Keep entries concise — lines after 200 are truncated.

Two-Step Save Workflow

Saving a memory always requires two tool calls:

1. MemoryCreate — write the new memory file with frontmatter
2. MemoryInsert or MemoryStrReplace — add/update the pointer line in MEMORY.md

Available Tools

1. MemoryView — Read a File or List a Directory

Returns file contents with line numbers, or a two-level directory listing with file sizes.

Parameters: - path (required) — relative path from the memories root; empty string or "/" for the root - viewRange (optional) — "start,end" to page through a large file (e.g. "1,50")

// View the index
String index = memoryTools.memoryView("MEMORY.md", null);

// View a specific memory file
String content = memoryTools.memoryView("user_profile.md", null);

// Page through a large file
String page = memoryTools.memoryView("feedback_testing.md", "1,30");

// List the root directory (shows all memory files)
String listing = memoryTools.memoryView("", null);

Output — file:

File: user_profile.md
Lines 1-8 of 8

     1  ---
     2  name: user profile
     3  description: Christian Tzolov — Spring AI lead at Broadcom
     4  type: user
     5  ---
     6
     7  Leads the Spring AI project at Broadcom.
     8  Prefers concise, direct responses.

Output — directory:

Contents of /:

  MEMORY.md (185 bytes)
  feedback_testing.md (312 bytes)
  user_profile.md (201 bytes)
  project/
    artemis_launch.md (148 bytes)

---

2. MemoryCreate — Create a New Memory File

Creates a new file with the given content. Errors if the file already exists.

Parameters: - path (required) — relative path for the new file (e.g. "user_profile.md", "project/sprint.md") - fileText (required) — full file content including the YAML frontmatter block

String result = memoryTools.memoryCreate("user_profile.md", """
    ---
    name: user profile
    description: Christian Tzolov — Spring AI lead at Broadcom
    type: user
    ---

    Leads the Spring AI project at Broadcom.
    Prefers concise, direct responses without trailing summaries.
    """);
// Returns: "Successfully created file: user_profile.md (201 bytes)"

After creating the file, add a pointer to MEMORY.md using MemoryInsert:

memoryTools.memoryInsert("MEMORY.md", currentLineCount,
    "- [User Profile](user_profile.md) — Christian Tzolov, Spring AI lead at Broadcom");

What NOT to save (belongs in conversation history, not long-term memory): - Ephemeral task details, in-progress steps, or current conversation context — these live in the session and disappear naturally - Code patterns, conventions, or architecture (derivable from the codebase at any time) - Git history or who changed what (git log is authoritative) - Debugging recipes (the fix is in the code; the commit message has context)

---

3. MemoryStrReplace — Replace Exact Text in a File

Replaces an exact, unique string in an existing memory file. Rejects the edit if the target string appears more than once.

Parameters: - path (required) — relative path to the file to edit - oldStr (required) — exact text to replace (must appear exactly once) - newStr (required) — replacement text; use "" to delete the matched text

// Update stale content in a memory file
memoryTools.memoryStrReplace("user_profile.md",
    "Leads the Spring AI project at Broadcom.",
    "Leads the Spring AI project at Broadcom. Also working on agent tooling.");

// Update a description in the frontmatter
memoryTools.memoryStrReplace("user_profile.md",
    "description: Christian Tzolov — Spring AI lead at Broadcom",
    "description: Christian Tzolov — Spring AI lead, agent tooling focus");

// Update the MEMORY.md pointer when a description changes
memoryTools.memoryStrReplace("MEMORY.md",
    "- [User Profile](user_profile.md) — Christian Tzolov, Spring AI lead at Broadcom",
    "- [User Profile](user_profile.md) — Christian Tzolov, Spring AI lead, agent tooling focus");

// Delete a line (empty newStr)
memoryTools.memoryStrReplace("feedback.md", "\nOutdated note to remove.", "");

When newStr is empty (deletion), the tool confirms the removal without returning a snippet. Otherwise it returns a numbered snippet around the edited location.

---

4. MemoryInsert — Insert Text at a Line Number

Inserts text after a given 1-indexed line number (0 inserts before the first line). Primary use is appending new pointer entries to MEMORY.md after Step 1 of the two-step save.

Parameters: - path (required) — relative path to the file to modify - insertLine (required) — line number after which to insert (0 = before line 1; total line count = append) - insertText (required) — text to insert

// Append a new entry to MEMORY.md (most common use)
// First, find the current line count via MemoryView
memoryTools.memoryInsert("MEMORY.md", currentLineCount,
    "- [Feedback Testing](feedback_testing.md) — always use real DB in integration tests");

// Insert a new section into an existing memory file
memoryTools.memoryInsert("project_auth.md", 6,
    "\n**Update 2026-04-05:** legal approved the revised token storage approach.");

The original trailing newline of the file is preserved after the insert.

---

5. MemoryDelete — Delete a File or Directory

Deletes a file or recursively deletes a directory. The memories root itself cannot be deleted.

Parameters: - path (required) — relative path to the file or directory to delete

// Delete a stale memory file
memoryTools.memoryDelete("project_old_sprint.md");
// Returns: "Successfully deleted file: project_old_sprint.md"

// Delete a subdirectory and all its contents
memoryTools.memoryDelete("archived/");
// Returns: "Successfully deleted directory: archived/"

Important: After deleting a memory file, always remove its entry from MEMORY.md using MemoryStrReplace to keep the index accurate.

---

6. MemoryRename — Rename or Move a File/Directory

Moves a file or directory to a new path within the memories root. Creates destination parent directories automatically.

Parameters: - oldPath (required) — current relative path - newPath (required) — new relative path (must not already exist)

// Rename a file
memoryTools.memoryRename("feedback.md", "feedback_testing.md");
// Returns: "Successfully renamed 'feedback.md' to 'feedback_testing.md'"

// Move into a subdirectory
memoryTools.memoryRename("old_project.md", "archived/old_project.md");

Important: After renaming, update the corresponding link in MEMORY.md using MemoryStrReplace.

Builder Configuration

AutoMemoryTools tools = AutoMemoryTools.builder()
    .memoriesDir("/path/to/memory")   // Path or String; default: /memories
    .build();

Builder method	Type	Default	Description
memoriesDir(Path)	Path	/memories	Root directory for all memory files
memoriesDir(String)	String	/memories	Same, accepts a string path

The directory is created automatically on build() if it does not exist. The path is normalized in the constructor, so ../relative/paths resolve correctly before the traversal guard is applied.

Security

All paths passed to the tools are resolved relative to memoriesDir:

• Absolute paths — rejected immediately (Error: Absolute paths are not allowed)
• Path traversal — ../../etc/passwd is caught after normalization (Error: Path traversal attempt detected)

The check uses Path.isAbsolute() before resolving, then verifies that the normalized result still starts with the normalized memoriesDir.

System Prompt

The companion system prompt AUTO_MEMORY_TOOLS_SYSTEM_PROMPT.md is bundled in the jar at classpath:/prompt/AUTO_MEMORY_TOOLS_SYSTEM_PROMPT.md. Include it alongside your main system prompt to instruct the agent on:

• The distinction between long-term memory (AutoMemoryTools) and the current session's conversation history — only facts worth keeping across conversations belong in memory files
• When and how to read, save, update, and delete memories
• The two-step save workflow
• The four memory types and their purposes
• What not to save (ephemeral state, code patterns, git history, fix recipes)
• Staleness checking before acting on recalled memories

The prompt contains one template placeholder: {MEMORIES_ROOT_DIERCTORY} (note the intentional spelling), which should be filled with the configured memories directory path so the agent can reference it in responses.

chatClientBuilder.defaultSystem(p -> p
    .text(mainPrompt + "\n\n" + memoryToolsPrompt)
    .param("MEMORIES_ROOT_DIERCTORY", memoryDir));

Demo Application

See memory-tools-demo for a complete working example. It demonstrates:

• Combining MAIN_AGENT_SYSTEM_PROMPT_V2.md and AUTO_MEMORY_TOOLS_SYSTEM_PROMPT.md
• Configuring AutoMemoryTools with a path from application.properties
• Using ToolCallAdvisor for recursive tool calling
• A console chat loop that builds up memory across turns

Inspiration

AutoMemoryTools is a Spring AI implementation of the memory patterns pioneered by Anthropic:

• Claude Code — Memory — describes how Claude Code uses a file-based memory system (MEMORY.md index, typed memory files, two-step save workflow) to persist knowledge across coding sessions. The file conventions, memory types (user, feedback, project, reference), and MEMORY.md index pattern in this library are directly inspired by that design.

• Claude API SDK — Memory Tool — the official Anthropic memory tool specification that defines the six memory operations (view, create, str_replace, insert, delete, rename) and the sandboxed /memories directory model. Each AutoMemoryTools method maps one-to-one to an operation in that spec.

AutoMemoryTools brings both designs to any Spring AI application regardless of the underlying model provider.

See Also

• Claude Code — Auto-Memory — the file-based memory system this library is modelled after
• Claude API SDK — Memory Tool — the official tool specification
• FileSystemTools — general-purpose file read/write/edit (not scoped to a sandbox)
• TodoWriteTool — task tracking within a single conversation
